If you own a Ford F-150, Transit, or any vehicle equipped with the powerful 3.5L EcoBoost engine, you know that the timing chain replacement is a major job. Mess it up, and you risk a catastrophic, terminal engine failure.
Having fixed these exact issues countless times, we're breaking down the top three most common EcoBoost timing chain mistakes that owners and mechanics keep making. Avoid these errors, and you’ll save yourself time, money, and the disaster of a blown engine.
1. Mistake #1: Not Replacing Everything While You’re In There
A timing chain replacement is not just about the chain itself. Since you are performing the extensive labor of removing the front timing cover, you must replace every single component that interacts with the chain.
The biggest mistake is attempting to save money by reusing old parts:
-
Tensioners and Guides: If you reuse a worn-out hydraulic tensioner or plastic guide, a brand-new chain will quickly become loose, resulting in a rattle or, worse, jumping a tooth.
-
Gaskets and Seals: Reuse the old timing cover or oil pan gaskets, and you are guaranteed to cause leaks. Once this big job is complete, you do not want to tear into it again for a preventable oil leak.
Pro Tip: Always use an OEM or high-quality aftermarket kit that includes the new chain, all guides, all tensioners, and all necessary seals. Watch the full video for a visual step-by-step breakdown of the job.
2. Mistake #2: Skipping the Oil Pan Removal and Deep Cleaning
When a timing chain—especially one that has been rattling due to worn-out guides—fails, it is not a clean break. Debris, hard plastic fragments from the guides, and metal shavings fall directly into your oil pan.
If you skip the oil pan removal and cleaning, you create an engine-killing risk:
"All that debris can get sucked into your oil pickup tube. Once that pickup is clogged, your oil pressure will drop. You're not just asking for another timing chain failure; you're risking a complete engine failure."
A clogged oil pickup starves the top end of the engine, leading to premature wear and failure. This step only adds an hour to the job, but it is the single most important insurance against future catastrophic engine failure.
3. Mistake #3: Incorrectly Lining Up the Timing Marks
This is the most critical mistake, and one that requires the most patience. If the chain is off by even a single tooth when connecting the cam pulleys and the crank pulley, your engine's internal combustion timing will be wrong, forcing you to tear the entire job back down.
The Golden Rule for Mechanics: "Check twice, torque once."
-
Line Up: Ensure the colored chain links line up exactly with the marks on your cam sprockets and the corresponding mark on the crankshaft pulley.
-
Verify: Once everything is secured and the tensioners are set, manually rotate the engine by hand two full revolutions (720 degrees).
-
Check: After the rotations, the timing marks must realign where they should be. This verifies that the chain tension is correct and the timing is perfect.
If you're dealing with misfire codes, especially P0340/P0345, before or after this job, you may have a faulty sensor or timing issue. See our in-depth guides for diagnosis:
-
Diagnosis Resource 1: ⚙️ 2017 Ford Explorer Camshaft Position Sensor – Location, Symptoms, and Easy DIY Diagnosis
-
Diagnosis Resource 2: ⚡ Fixing P0302 in Your 3.5L EcoBoost: 2017 Ford Explorer Cylinder 2 Misfire Diagnosis
🛠️ Final Bonus Tip: Preparation and Safety
Before you even start tearing down the front of the engine, always prioritize safety and preparation. Ensure your vehicle is properly supported.
Avoid these critical mistakes, and your EcoBoost will run strong for years to come.
