Introduction: More Than Just a Swap
The fifth-generation Ford Explorer (model years 2011 through 2019) represents a significant technological leap in automotive engineering. While the fundamental task of replacing a 12-volt battery might appear straightforward, modern vehicle architecture demands a detailed, expert approach. Unlike older cars, simply swapping the battery is only half the job; failing to account for the sophisticated electrical management systems embedded within these vehicles can lead to premature battery failure and complex electronic issues.
This comprehensive guide transforms the basic practical steps demonstrated in typical(https://youtu.be/HclyAV41QiU) video tutorials into an authoritative reference manual for the advanced enthusiast. The primary focus here is to supplement the physical replacement procedure with crucial technical specifications, rigorous safety protocols, and the non-negotiable requirement of resetting the Battery Management System (BMS). The integration of complex electrical demands—such as those required by infotainment systems, advanced driver-assistance systems (ADAS), and auto start-stop functions—means that ignoring the BMS guarantees subsequent system malfunction and a dramatically shortened lifespan for the newly installed battery. Working with automotive batteries involves handling highly corrosive acid and managing the risk of explosive hydrogen gas emission, making adherence to strict safety protocols absolutely essential.
Phase 1: Diagnostics, Preparation, and Technical Selection
1.1 Confirming the Actual Problem
Before dedicating resources to purchasing and installing a new battery, the user must definitively verify that the battery, and not another component, is the source of the electrical issue. It is a frequent error in automotive diagnostics to automatically attribute starting or electrical problems to the battery. If a vehicle owner replaces a healthy battery when the true culprit is a malfunctioning alternator or a significant parasitic draw, they incur an unnecessary expense and fail to resolve the underlying mechanical fault.
A critical preliminary step involves testing the electrical system. The engine should be started and the voltage across the battery terminals measured with a multimeter. A healthy charging system should produce a stable output exceeding 14 volts. If the vehicle fails to produce adequate voltage (e.g., dropping below 14 volts) or if a dashboard warning light persists, the issue may stem from the alternator or the wiring connecting it to the battery and the Battery Management System (BMS). For a comprehensive battery check, testing the Cold Cranking Amperage (CCA) and resting voltage (ideally above 12.4 V when the car is off) will confirm if the existing battery has degraded beyond recoverable limits.
1.2 Non-Negotiable Safety Protocols
The successful and safe replacement of an automotive battery requires strict adherence to safety guidelines, given the risks associated with sulfuric acid and highly flammable hydrogen gas produced during charging.
Safety and Environmental Controls
All work must be performed in a highly ventilated area, ideally outdoors, to ensure that any accumulation of explosive gases is swiftly dispersed. Protective gear is mandatory; this includes wearing safety glasses and insulating gloves throughout the procedure to protect the eyes and skin from accidental contact with battery acid. Furthermore, all metal jewelry, especially rings, bracelets, and watches, must be removed. Accidental contact between a metal object and both battery terminals simultaneously, or between the positive terminal and the grounded metal chassis, can instantly cause a severe electrical short, resulting in dangerous sparks and severe burns.
Memory Preservation and ECU Protection
A crucial technical requirement for modern Ford Explorers is power maintenance during the battery swap. These vehicles rely heavily on complex, integrated electronic control units (ECUs) to manage everything from engine performance (idle parameters, fuel trims) to driver convenience features (radio presets, navigation data) and safety systems (ADAS). If the power supply is completely severed, these volatile memories can be lost. While the immediate consequences might seem minor (e.g., losing radio stations), a complete power loss risks triggering complex fault codes that may require specialized diagnostic scan tools to reset, potentially forcing an unexpected and costly appointment with a mechanic.
To mitigate the risk of ADAS and ECU failure, a memory saver device must be utilized. This device, typically plugged into the OBD-II diagnostic port or a 12-volt auxiliary socket, maintains a small trickle charge to the vehicle's electrical system, keeping critical systems "alive" while the main power source is disconnected.
1.3 Selecting the Correct Battery (Group Size and Specs)
Verification of the appropriate battery specifications is paramount, as installing a battery with insufficient cold cranking amperage (CCA) or an incorrect physical size will lead to inadequate starting power and potential instability in the battery tray. The fifth-generation Ford Explorer typically uses one of two primary BCI (Battery Council International) group sizes, depending on the vehicle's specific package and installed options.
BCI Group Size Variations
The two most common sizes are Group 65 and Group 59. Group 65 batteries are generally found in models equipped with higher electrical demands, such as those featuring "Intelligent Access" or extensive factory electronics. These units offer high CCA ratings, typically ranging from 750A to 850A, and robust reserve capacity (RC) of 120 minutes or more. Conversely, Group 59 batteries are standard in lower-trim models without Intelligent Access. These batteries feature lower specifications, usually 540A to 590A CCA and 100 minutes RC.
The advanced DIYer must prioritize dimensional fit alongside electrical specifications. The physical size difference between the Group 65 and Group 59 is significant (Group 65 is approximately 12.06 inches long, while Group 59 is about 10.06 inches long). Selecting the correct physical dimensions ensures the battery rests securely in the tray and that the hold-down clamp can be tightened appropriately, preventing dangerous movement or vibration damage during operation. It is essential to physically check the BCI Group Size printed on the existing battery before procuring a replacement.
Ford Explorer (2011-2019) Battery Specification Reference
| BCI Group Size | Typical CCA Range | Reserve Capacity (Min) | Approximate Length (In.) | Common Use Case |
| 65 | 750A – 850A | 120 – 150 | ~12.06 | Intelligent Access, High Electrical Demand |
| 59 | 540A – 590A | 100 | ~10.06 |
Standard Model, Without Intelligent Access |
1.4 The Upgrade Decision: AGM vs. Flooded Lead-Acid
When selecting a battery, a critical decision involves choosing between traditional Flooded Lead-Acid technology and the more modern Absorbent Glass Mat (AGM) technology.
Technical Comparison
Standard flooded lead-acid batteries are typically the cheaper option, offering reliable performance with a lifespan of approximately three to five years. While many modern flooded batteries are sealed, historically, they required occasional maintenance.
AGM batteries offer significant performance advantages. They utilize fiberglass mats tightly packed between the lead plates to absorb the electrolyte, making them sealed, spill-proof, and maintenance-free. This design allows for tighter packing of the lead plates, reducing internal resistance and enabling the battery to deliver more power while being less susceptible to sulfation, a common cause of premature failure in flooded batteries.
Performance and Longevity
AGM batteries excel in high-demand environments. They perform better in conditions of consistent high heat, as the sealed design minimizes electrolyte evaporation, a factor that rapidly degrades standard lead-acid batteries in warm climates. Crucially, AGM batteries handle deep cycling (repeated discharge and recharge) much more effectively than flooded batteries. Given the high electrical demands and complex charging cycles imposed by modern Ford Explorer features (such as sophisticated charging algorithms and occasional auto start-stop functions), upgrading to an AGM battery is strongly recommended for enhanced longevity and reliability, offering a lifespan that can be two to three times longer than standard batteries, potentially lasting up to 10 years.
Phase 2: Step-by-Step Procedure (Removal and Installation)
2.1 Required Tools
A streamlined replacement procedure requires the preparation of the necessary tools, which typically include a 10mm wrench (essential for terminal nuts), an 8mm wrench (often required for the battery hold-down clamp), an extension and ratchet (to easily reach fasteners deep within the engine bay), a battery terminal brush, and potentially a flathead screwdriver or fastener removal tool for clips. The memory saver device must also be ready and connected before disconnection commences.
2.2 Disconnecting and Removal
The sequence of disconnection is critical for electrical safety and must be followed precisely.
Step 1: Disconnect the Negative Terminal
The primary rule of battery safety dictates that the negative (-) cable must always be disconnected first. This cable is the vehicle's primary ground connection to the chassis. By removing the negative cable first, the electrical connection between the battery and the vehicle body is severed, neutralizing the risk of generating a spark or short circuit if a tool accidentally touches the positive terminal and any grounded metal component simultaneously. Use the 10mm wrench to loosen the nut on the negative terminal, remove the cable, and secure it away from the battery and surrounding metal surfaces.
Step 2: Disconnect the Positive Terminal and Accessories
The positive (+) terminal is frequently located beneath a red protective cover. The Ford Explorer introduces a layer of complexity here: the positive terminal often serves as a junction point for multiple auxiliary electrical accessories and fuses connected beneath the main cable. This specific challenge is often detailed in repair guides like the(https://youtu.be/HclyAV41QiU). The technician must meticulously loosen and remove the main positive cable and then carefully identify, document, and remove any accessory connections attached beneath it. Failure to properly account for and reattach these auxiliary connections can result in component failure for systems like navigation, infotainment, or Intelligent Access.
Step 3: Remove the Hold-Down Clamp
Locate the battery hold-down mechanism. This is typically a plastic or metal clamp secured by a bolt, often requiring an 8mm or 13mm socket. Loosen and remove the fastener, freeing the battery from its tray.
Step 4: Lift and Inspect
Carefully lift the old battery out. Automotive batteries are heavy, and proper lifting techniques should be used. Once the old battery is removed, inspect the battery tray for excessive corrosion or debris.
2.3 Preparation and Installation
Preparing the surface and connections is vital for maximizing the lifespan and performance of the new battery.
Step 5: Cleaning and Preparation
Thoroughly clean the battery tray, ensuring a smooth, level surface for the new battery to rest on. If corrosion (often a white or blue powder) is present, neutralize it and clean the area. Crucially, use a wire battery brush to clean the inside surfaces of both the positive and negative cable ends. A clean connection ensures low electrical resistance, guaranteeing that the new battery can deliver maximum current and receive a proper charge.
Step 6: Install New Battery and Hold-Down
Place the new battery securely onto the cleaned tray. Install any insulating shield or liner that was present. Reinstall the battery hold-down clamp and tighten its fasteners securely. The battery must be firmly clamped down to prevent movement that could damage internal plates or cause premature failure.
Step 7: Connect the Positive Terminal
Reversing the removal process, the positive (+) cable must be connected first. Reattach all documented auxiliary accessory cables to the positive post. Tighten the main cable nut securely and replace the protective cover.
Step 8: Connect the Negative Terminal
Connect the negative (-) cable to the negative terminal last. Tighten the cable nut securely. This step completes the electrical circuit. At this point, the memory saver device can be safely removed, and the vehicle is ready for the final, essential step: the BMS reset.
Phase 3: The Battery Management System (BMS) Imperative
3.1 Understanding the BMS and Its Role
The Battery Management System (BMS) is a complex, adaptive software system installed in modern Ford vehicles to optimize charging efficiency and prolong battery life. It constantly monitors various parameters, including the battery’s age, temperature, state of charge (SOC), and internal resistance.
As a standard flooded lead-acid battery ages (typically over 3–5 years), its capacity to accept a charge diminishes, and its internal resistance naturally increases. The BMS learns and adapts to this degradation by incrementally increasing the charging voltage delivered by the alternator to ensure the old, struggling battery stays topped up.
The Critical Consequence of Neglecting the Reset
When a brand-new battery is installed, it possesses very low internal resistance and full capacity. If the adaptive BMS charging parameters are not reset, the vehicle's charging system will continue to apply the old, high-voltage profile intended for the severely degraded battery. This chronic overcharging leads to excessive internal heat, electrolyte boiling (if flooded), accelerated plate sulfation, and dramatically reduces the lifespan of the new battery, often causing failure within 12 to 18 months. Therefore, the BMS reset is not optional; it is the single most important maintenance step for ensuring the new battery achieves its intended longevity.
3.2 The Ford DIY BMS Reset Procedure (2011-2019)
Ford provides a specific, manual procedure utilizing dashboard controls to reset the BMS charging parameters. This resets the "age counter," informing the vehicle's computer that a new battery has been installed and instructing the BMS to revert to the factory-fresh charging voltage parameters.
The following sequence is recognized for many 2011-2019 Ford Explorer models :
Critical Step-by-Step DIY Reset
| Step | Action | Required Condition | Confirmation/Note |
| 1 | Engage Accessory Mode | Key in, DO NOT press the brake pedal, push the start button once. | All dashboard lights illuminate; the engine remains off. |
| 2 | Flashers (5 times) | Pull the headlight/hazard flashers quickly and consistently, five (5) times. | Activates the reset sequence trigger. |
| 3 | Brake Pedal (3 times) | Apply the brake pedal three (3) times, immediately following the flashers. | Initiates the BMS learning process. |
| 4 | Wait for Indicator | The battery indicator light on the dash will blink rapidly for a few seconds, then stop blinking. |
Cessation of blinking confirms the successful reset of the charging parameters. |
| 5 | Shut Down | Turn off Accessory Mode by pressing the start button again. | System is ready for operation. |
3.3 Advanced Registration and Tools
While the manual dashboard sequence successfully resets the primary charging parameters (the "age counter"), a distinction exists between a simple reset and comprehensive registration. In certain late-model vehicles, especially when performing a significant upgrade—such as switching from a standard flooded battery to an AGM type—the vehicle's computer may need to be explicitly programmed with the new battery's chemistry, cold cranking amperage (CCA), and capacity.
For vehicles that demand this level of precision, particularly if upgrading the battery chemistry, the DIY dashboard reset may only adjust the aging curve but fail to fully optimize the voltage profile required by the AGM technology. Applying a charging profile intended for a flooded battery to an AGM battery can still lead to inefficiency or reduced lifespan. In these scenarios, professional registration using an OBD-II scanner equipped with proprietary Ford software (or a high-end aftermarket tool) is the recommended path. This tool forces the Battery Control Module to accept and implement the specific charge characteristics of the new unit. If electronic anomalies or persistent battery messages occur after the manual reset, seeking professional registration is the necessary follow-up.
Phase 4: Common Mistakes and Longevity Best Practices
4.1 Major Mistakes to Avoid
The expertise displayed during the battery replacement procedure is often measured by the avoidance of common, yet serious, errors.
-
Incorrect Terminal Disconnection Order: The failure to disconnect the negative terminal first (and reconnect the positive terminal first) poses an immediate and severe safety risk due to the high probability of electrical shorting.
-
Ignoring Accessory Connections: The positive terminal on the Ford Explorer often manages power distribution for multiple vehicle subsystems. Removing the main cable without documenting and securely reattaching all auxiliary wires hidden beneath the red cap can lead to immediate failure of those electronic components.
-
Skipping the BMS Reset: As established, skipping the BMS reset subjects the new battery to the accelerated degradation protocols intended for the old unit, directly causing premature failure and minimizing return on investment.
-
Neglecting Surface and Terminal Cleanliness: Leaving corrosive residue in the battery tray compromises the stability and integrity of the new unit. Furthermore, corroded cable ends dramatically increase electrical resistance. This resistance not only makes starting difficult but also impedes the battery's ability to receive a full, efficient charge from the alternator.
4.2 Maximizing New Battery Lifespan
Protecting the new battery extends beyond the installation procedure; it requires ongoing vigilance and operational awareness.
System Integrity Checks
A primary determinant of battery longevity is the health of the charging system. Even the best battery will fail prematurely if the alternator is providing unstable or incorrect voltage. The electrical system should be regularly monitored to ensure the alternator consistently maintains the required charging voltage (typically 14V to 14.8V) once the engine is running.
Operation and Chemistry Optimization
Users should be aware that frequent short trips, especially in urban environments, often do not allow the alternator enough time to fully replenish the energy expended during engine starting, leading to a chronically undercharged state (deep cycling). This issue is exacerbated by heavy reliance on accessories (e.g., using navigation or infotainment while the engine is off). For owners who frequently experience these conditions, the decision to upgrade to an AGM battery is highly advantageous, as AGM chemistry is fundamentally designed to tolerate deeper discharge cycles and rebound faster than standard flooded batteries.
Conclusion: Driving Away with Confidence
Replacing the battery in a 2011–2019 Ford Explorer is a nuanced maintenance task that requires precision across three critical phases: rigorous safety and technical selection, meticulous physical replacement (especially concerning the complex terminal accessory management), and the non-negotiable electronic adjustment of the Battery Management System.
The fundamental shift in modern automotive design—where the battery is viewed as an integrated electrical component managed by adaptive software—means that the process is incomplete without the BMS reset. By strictly adhering to professional safety protocols, verifying the correct BCI Group Size (65 or 59), cleaning all connection points, and executing the mandatory BMS dashboard reset sequence (as demonstrated in helpful tutorials like the(https://youtu.be/HclyAV41QiU) ), the advanced DIYer ensures not only immediate starting success but also the long-term health and optimal charging profile for their vehicle's complex electrical architecture, thus maximizing the lifespan of the new investment.
